50 Watt Power Amplifier Kit

SKU

FK660

In stock

$19.95

Overview

50 Watt Mono OCL Power Amplifier Kit 1% Resistors. Class AB circuit, 1V. input sensitivity and 15 K input resistance.

FK660ﾠ 50 WATT MONO POWER AMPLIFIER KIT

This is a complementary class AB circuit main amplifier
Input sensitivity 1V and 15 K input resistance.
Transformer required: 24-0-24V. 640-483
Power Supply +/-35VDC max, 3A
Frequency Response 10 - 100kHz (+/-1dB)
Output power 50 Watts RMS Clas AB @ 4 or 8 ohms
Total Harmonic Distortion 0.02%
Dimensions of PCB 4.5 x 1.78"
